TECHNOLOGY
ST-poly processing
Achilles’ original conductive coating
“ST-poly” is a conductive polymer of transparent, clean, and independent of humidity.
Post-processing with this polymer electrically conducts the surface of insulating materials, such as molded plastic products, films, and fabrics. The thin layer retains the shape and texture of the base material.
Features
- ESD prevention – Surface resistance: 10^3 Ω < R < 10^8 Ω
- Stable performance – Conductive properties are maintained over time.
- High transparency – Approximately 80% light transmittance
- Cleanliness – Low outgassing, low ion contamination, silicon-free
- Heat-resistant – Conductive even when heated to 200°C for 3 minutes
Compatibile base materials
The followings table contains examples of materials that we have extensive experienced with.
If you are considering using other materials, please feel free to inquire with us, since our past experience can be used to help you work with new materials as well.
| Base material | |
|---|---|
| ABS | Acrylonitrile butadiene styrene |
| A-PET | Amorphous-polyethylene terephthalate |
| PA6 | Nylon 6, or Polycaprolactam |
| PA66 | Nylon 66, or Polyamide 66 |
| PAN | Polyacrylonitrile |
| PC | Polycarbonates |
| PE | Polyethylene |
| PEEK | Polyetheretherketone |
| PEI | Poly-ether-imide |
| PES | Polyethersulphone |
| PET | Polyethylene terephthalate |
| PI | Polyimides |
| PP | Polypropylene |
| PS | Polystyrene |
| PVC | Polyvinyl chloride |
